Linka® Bag-filter

A bag-filter with an integrated cleaning system that optimises the purification of biomass boiler flue gases.

From 1 January 2025, existing medium-sized biomass plants commissioned before 20 December 2018 with a nominal thermal input exceeding 5 MW must comply with emission limit values for SO2, NOx, particulate matter, and CO as per as per your national executive order for implementation og
the MCP-Directive.
The new requirements will necessitate the installation of a filter system, such as a bag-filter, on all biomass plants.
Linka can assist in understanding the directive and the tightened emission requirements, thereby enhancing the reputation of biomass combustion. Linka offers a bag-filter with an integrated cleaning system for purifying flue gases from biomass boilers.

Claus M. Larsen

Project sales

Contact me

Linka® offers a bag-filter that removes fine ash particles from the flue gas.

Facts

  • Fully complies with current regulations for meeting emission requirements (MCP Directive).
  • The filter is assembled in segments made of steel plates.
  • Top doors are mounted on the filter for inspection and service purposes.
  • The service area has a handrail installed, and a staircase leading to the ground.
  • All external surfaces are insulated with mineral wool.
  • The cladding is made of plastic-coated aluminium sheets in a standard colour of the customer’s choice.
  • Easy to connect to existing installations.

The energy consumption of the bag-filter is modest, and it requires only minimal maintenance – as we say at Linka:

Think about the working environment – avoid fly ash in the boiler room.

The technology behind a bag-filter

The bag-filter is used for purifying flue gases from biomass boilers and is an efficient and reliable solution that combines several advanced technologies for optimal performance and low maintenance.
The filter is equipped with a necessary service platform on the “filter top” and at the lower inspection door on the flat scraper bottom of the filter. Additionally, it is designed as a buffer tank and is equipped with a robust hub and gear system sized to rotate and empty fly ash from the filter’s scraper bottom. The filter baskets are made of either black steel or AISI (stainless steel) and are split in two or three parts depending on filter height.
The filter is fitted with a spark arrestor and filter bags expected to have a lifespan of 4-5 years. The filter bags are available in 3 different qualities depending on the boiler’s flue gas temperature.
The filter is equipped with three bypass dampers which, in emergency situations, can divert the flue gas past the filter during startup, shutdown, and operation. This bypass damper is activated if temperatures exceed what the bags can handle. Additionally, the filter has standstill heating to keep it dry and warm during standby periods. The standby heating circuit can be equipped with an energy meter to register how much heat is used for this process.

The filter is insulated with mineral wool (100 mm indoors / 200 mm outdoors) and has a service platform on top as well as an inspection door at the bottom.
The filter cleaning system is not just a fully automatic cleaning system, meaning it doesn’t just clean based on a certain pressure differential, but it is programmed to clean based on varied pressure differentials.
This means, for example, that it starts the cleaning cycle at a pressure differential of 80 mmWC – at 100% plant load, and the setpoint for starting the cleaning cycle varies with increasing and decreasing plant load. For example, at a plant load of 70%, the cleaning cycle will start at 56 mmWC. This ensures that there is always approximately the same amount of fly ash on the filter medium regardless of significant variations in plant load.

It is a definite advantage that there is always the same amount of ash on the filter medium and the filter medium is never exposed to any sticky particles in the flue gas. At the same time, there will be a modest energy saving as the pressure drop across the filter is reduced with decreasing plant load.
The filter’s cleaning system is extremely efficient, where one row of filter bags is cleaned via a “shot tube” which delivers a pressure pulse of air into the bags.
Afterward, the flue gas is drawn through the frequency-controlled flue gas fan and subsequently out into the chimney.

Advantages

  • Low filter load, which extends the lifespan of the filter bags.
  • Automatic cleaning controlled via a valve control system.
  • Reliable operation using standard components that do not require service from specially trained technicians.
  • The filter’s cleaning system has no moving parts apart from the mechanical movement in the diaphragm valves and the scraper arm at the bottom of the filter.
  • Inexpensive to operate.
  • Requires less supervision.
  • An investment that can pay off over time.
  • Easy to integrate with an existing system.
